Straight Shanks for Tuff Caps
Straight Shank for Tuff Caps are designed for use with Variable Offset Holders and allow users to modify the offset by positioning the tip in place then tightening the set screw to lock the tip in place. The shanks are available with different engagement angles to provide maximimum flexibility.
| Part | Description | RWMA Material Type | Shank Enagement Dia. | Taper for Cap | Overall Length | Offset | Unit of Measure | Angle of Engagement |
|---|---|---|---|---|---|---|---|---|
| 170-4422 | SE-4412 SHANK | RWMA Class 2 - C18200 | 0.625 IN diameter | 5RW Cap Taper | 3.00000 | 0.7500 | IN | 90.0 |
| 170-4423 | SE-4413 SHANK | RWMA Class 2 - C18200 | 0.625 IN diameter | 5RW Cap Taper | 3.00000 | 0.7500 | IN | 15.0 |
| 170-4424 | SE-4414 SHANK | RWMA Class 2 - C18200 | 0.625 IN diameter | 5RW Cap Taper | 3.00000 | 1.0000 | IN | 90.0 |
| 170-4425 | SE-4415 SHANK | RWMA Class 2 - C18200 | 0.625 IN diameter | 5RW Cap Taper | 3.00000 | 1.0000 | IN | 15.0 |
